Falcon 75

The Falcon 75 Automated Cone Laying Machine (ACLM) brings our award-winning automated cone laying technology to local and rural roads with a smaller, more agile vehicle packed with all the functionality of the larger model.

Designed to help protect road workers from the risks of conventional cone laying, the Falcon 75 ACLM automates the process and reduces the need for workers in the carriageway or on the rear of the vehicle. Mounted on the back of a 2300mm wide flatbed truck chassis, it can deploy up to 7 cones/minute and collect up to 6 cones/minute with reliable, repeatable accuracy. The machine is powered by a 48 VDC/180 Ah battery, which enables approximately 600 cone cycles on a single charge. The ACLM Falcon 75 is available in three capacity arrangements, ranging from 240 to 480 cones in each machine.

Features and Benefits

✓ Ideal for local and rural roads for use with 750mm, 5kg cones

✓ Various modes for different traffic management settings, including pre-set modes for medium and narrow lanes

✓ Rapid cone deployment up to 7 cones/minute and collects up to 6 cones/minute

✓  Small enough to operate on narrower roads that are less straight or come with height restrictions and require a smaller vehicle to suit the needs of the operation

✓ Cone laying and taper intervals can be set by the operator

✓ Available in three capacity arrangements

✓ Cone laying is controlled and monitored from the cab

Vehicle capacity:

Falcon 75S (up to 240 cones)
Falcon 75M (up to 384 cones)
Falcon 75L (up to 480 cones)
